Arrays, Signal Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Number of Coils | Inductance - Connected In Parallel | Tolerance | Current Rating - Parallel | Current Rating - Series | Height | Current Saturation - Parallel | Current Saturation - Series | Inductance - Connected In Series | DC Resistance (DCR) - Parallel | DC Resistance (DCR) - Series | Size / Dimension | Shielding | Mounting Style | Ratings | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PF0553.334NLTINDUCT ARRAY 2 COIL 330UH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 330 µH | ±20% | 1 A | 510 mA | 0.315" (8.00mm) | 2 A | 1 A | 1.3 mH | 570mOhm Max | 2.3mOhm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
|
PF0553.105NLTINDUCT ARRAY 2 COIL 1MH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 1 mH | ±20% | 610 mA | 310 mA | 0.315" (8.00mm) | 1.1 A | 570 mA | 4 mH | 1.6Ohm Max | 6.5Ohm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
|
PF0553.332NLTINDUCT ARRAY 2 COIL 2.8UH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 2.8 µH | ±20% | 10 A | 5.2 A | 0.315" (8.00mm) | 21 A | 11 A | 11.3 µH | 5.4mOhm Max | 22mOhm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
|
PF0553.104NLTINDUCT ARRAY 2 COIL 100UH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 100 µH | ±20% | 1.9 A | 970 mA | 0.315" (8.00mm) | 3.6 A | 1.8 A | 400 µH | 160mOhm Max | 650mOhm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
|
PF0553.474NLTINDUCT ARRAY 2 COIL 470UH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 470 µH | ±20% | 830 mA | 420 mA | 0.315" (8.00mm) | 1.7 A | 840 mA | 1.9 mH | 860mOhm Max | 3.4Ohm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
|
PF0553.154NLTINDUCT ARRAY 2 COIL 150UH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 150 µH | ±20% | 1.6 A | 780 mA | 0.315" (8.00mm) | 3 A | 1.5 A | 600 µH | 250mOhm Max | 990mOhm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
P0398NLTINDUCT ARRAY 2 COIL 7.9UH SMD |
0 | - |
|
Datasheet |
Tomcat | Nonstandard | Tape & Reel (TR) | Active | 2 | 7.9 µH | ±20% | 6.8 A | 3.4 A | 0.310" (7.87mm) | - | - | 31.5 µH | 14.94mOhm | 59.7mOhm | 0.715" L x 0.590" W (18.16mm x 14.99mm) | Unshielded | Surface Mount | - | -40°C ~ 130°C |
|
|
PF0553.822NLTINDUCT ARRAY 2 COIL 8.9UH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 8.9 µH | ±20% | 6.2 A | 3.1 A | 0.315" (8.00mm) | 12 A | 6.1 A | 35 µH | 15mOhm Max | 62mOhm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
|
PF0553.823NLTINDUCT ARRAY 2 COIL 80UH SMD |
0 | - |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 80 µH | ±20% | 2 A | 1 A | 0.315" (8.00mm) | 4.1 A | 2 A | 320 µH | 140mOhm Max | 570mOhm Max | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielded | Surface Mount | - | -40°C ~ 125°C |
|
P0402INDUCT ARRAY 2 COIL 40.5UH SMD |
0 | - |
|
Datasheet |
Tomcat | Nonstandard | Tube | Obsolete | 2 | 40.5 µH | ±20% | 3.54 A | 1.77 A | 0.310" (7.87mm) | - | - | 161.8 µH | 53.21mOhm | 212.8mOhm | 0.715" L x 0.590" W (18.16mm x 14.99mm) | Unshielded | Surface Mount | - | -40°C ~ 130°C |
|
PM600-01-RCINDUCT ARRAY 6 COIL 201.6UH SMD |
0 | - |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 201.6 µH | ±30% | 2.76 A | 460 mA | 0.244" (6.20mm) | 120 mA | 20 mA | 7.25 mH | 54mOhm | 1.944Ohm | 0.500" L x 0.480" W (12.70mm x 12.20mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM600-02-RCINDUCT ARRAY 6 COIL 89.6UH SMD |
0 | - |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 89.6 µH | ±30% | 4.26 A | 710 mA | 0.244" (6.20mm) | 180 mA | 30 mA | 3.23 mH | 23mOhm | 822mOhm | 0.500" L x 0.480" W (12.70mm x 12.20mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM600-03-RCINDUCT ARRAY 6 COIL 27.4UH SMD |
0 | - |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 27.4 µH | ±10% | 2.76 A | 460 mA | 0.244" (6.20mm) | 1.86 A | 310 mA | 986.4 µH | 54mOhm | 1.944Ohm | 0.500" L x 0.480" W (12.70mm x 12.20mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM600-04-RCINDUCT ARRAY 6 COIL 12.2UH SMD |
0 | - |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 12.2 µH | ±10% | 4.26 A | 710 mA | 0.244" (6.20mm) | 2.82 A | 470 mA | 439.2 µH | 23mOhm | 822mOhm | 0.500" L x 0.480" W (12.70mm x 12.20mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM600-10-RCINDUCT ARRAY 6 COIL 3.8UH SMD |
0 | - |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 3.8 µH | ±10% | 4.26 A | 710 mA | 0.244" (6.20mm) | 11.1 A | 1.85 A | 136.8 µH | 23mOhm | 822mOhm | 0.500" L x 0.480" W (12.70mm x 12.20mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM610-01-RCINDUCT ARRAY 6 COIL 160UH SMD |
0 | - |
|
Datasheet |
PM610 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 160 µH | ±30% | 4.08 A | 680 mA | 0.307" (7.80mm) | 240 mA | 40 mA | 5.76 mH | 34mOhm | 1.212Ohm | 0.591" L x 0.630" W (15.00mm x 16.00mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
PM610-05-RCINDUCT ARRAY 6 COIL 11.6UH SMD |
0 | - |
|
Datasheet |
PM610 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 11.6 µH | ±10% | 4.08 A | 680 mA | 0.307" (7.80mm) | 7.8 A | 1.3 A | 417.6 µH | 34mOhm | 1.212Ohm | 0.591" L x 0.630" W (15.00mm x 16.00mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM610-10-RCINDUCT ARRAY 6 COIL 3.2UH SMD |
0 | - |
|
Datasheet |
PM610 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 3.2 µH | ±10% | 6 A | 1 A | 0.307" (7.80mm) | 19.74 A | 3.29 A | 115.2 µH | 16mOhm | 564mOhm | 0.591" L x 0.630" W (15.00mm x 16.00mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM620-01-RCINDUCT ARRAY 6 COIL 160.6UH SMD |
0 | - |
|
Datasheet |
PM620 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 160.6 µH | ±30% | 7.68 A | 1.28 A | 0.331" (8.40mm) | 180 mA | 30 mA | 5.78 mH | 16mOhm | 564mOhm | 0.669" L x 0.843" W (17.00mm x 21.40mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
|
|
PM620-03-RCINDUCT ARRAY 6 COIL 131.8UH SMD |
0 | - |
|
Datasheet |
PM620 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 131.8 µH | ±20% | 7.68 A | 1.28 A | 0.331" (8.40mm) | 480 mA | 80 mA | 4.74 mH | 16mOhm | 564mOhm | 0.669" L x 0.843" W (17.00mm x 21.40mm) | Unshielded | Surface Mount | - | -40°C ~ 105°C |
