STMicroelectronics VN5772AK-E
- Part No.:
- VN5772AK-E
- Manufacturer:
- STMicroelectronics
- Category:
- Full Half-Bridge (H Bridge) Drivers
- Package:
- 28-SOIC (0.295", 7.50mm Width)
- Datasheet:
-
VN5772AK-E.pdf
- Description:
- IC HALF BRIDGE DRIVER 18A 28SO
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:

- Shipping:

Inventory:0
Send us your inquiry,we will respond immediately.
In Stock : 0 PCS
| Qty. | Unit Price | Ext Price |
| 1+ | $0.000 | $0.000 |
*Products eligible for online ordering ship within 1-2 business days,please contact us for exact shipping times.
Also you can RFQ for VN5772AK-E or email to us: Email: [email protected] , we will contact you within 12 hours.
VN5772AK-E Specifications
- Specifications
- FAQ
- Attributes
- Property Value
- Manufacturer
- STMicroelectronics
- Series:
- OMNIFET III™, VIPower™
- Package/Case:
- 28-SOIC (0.295", 7.50mm Width)
- Packaging:
- Tube
- Part Status:
- Active
- Output Configuration:
- Half Bridge (2)
- Part Applications:
- DC Motors, General Purpose, Relays
- Load Type:
- Inductive, Capacitive, Resistive
- Technology:
- Power MOSFET
- Rds On (Typ):
- 50mOhm (Max)
- Mounting Style:
- Surface Mount
- Current - Output / Channel:
- 18A
- Current - Peak Output:
- -
- Interface:
- Logic
- Voltage - Supply:
- 4.5V ~ 36V
- Voltage - Load:
- 41V (Max)
- Fault Protection:
- Current Limiting, ESD, Over Temperature, Over Voltage, Short Circuit, UVLO
- Operating Temperature:
- -40°C ~ 150°C (TJ)
- Supplier Device Package:
- 28-SO
- Features:
- -
- Grade:
- -
- Qualification:
- -
- Category:
- Full Half-Bridge (H Bridge) Drivers
