Texas Instruments TMUX1309QDYYRQ1
- Part No.:
- TMUX1309QDYYRQ1
- Manufacturer:
- Texas Instruments
- Package:
- SOT-23-16 Thin, SOT-23 Variant
- Datasheet:
-
TMUX1309QDYYRQ1.pdf
- Description:
- IC SWITCH SP4TX2 195OHM 16SOT23
- Quantity:
Unit Price:$0.337800
Ext Price:$0.337800
- Payment:
- Shipping:
Inventory:36,985
Send us your inquiry,we will respond immediately.
In Stock : 36,985 PCS
| Qty. | Unit Price | Ext Price |
| 1+ | $0.337800 | $0.337800 |
| 3000+ | $0.241300 | $723.900000 |
*Products eligible for online ordering ship within 1-2 business days,please contact us for exact shipping times.
Also you can RFQ for TMUX1309QDYYRQ1 or email to us: Email: [email protected] , we will contact you within 12 hours.
Product Details
TMUX1309QDYYRQ1 - TI Dual-Channel SPDT Analog Switch
TMUX1309QDYYRQ1 is a dual-channel SPDT (Single-Pole-Double-Throw) analog switch, also known as a 2:1 multiplexer. It contains two independent SPDT switches, each controlled by a logic input pin. Operating from 1.65V to 5.5V with 3.5Ω typical ON-resistance and 300MHz bandwidth, it is ideal for signal...
Product Introduction
TMUX1309QDYYRQ1 is a dual-channel SPDT (Single-Pole-Double-Throw) analog switch, also known as a 2:1 multiplexer. It contains two independent SPDT switches, each controlled by a logic input pin. Operating from 1.65V to 5.5V with 3.5Ω typical ON-resistance and 300MHz bandwidth, it is ideal for signal routing in automotive, industrial, and portable electronics. The tiny SOT-23-6 package is AEC-Q100 Grade 1 qualified.
Expert Technical Insights
SPDT switch signal routing applications:
- The TMUX1309's dual SPDT configuration is perfect for audio source selection (routing one audio output between two speakers or headphones), voltage rail switching in power management, and USB-C alternate mode signal routing
- When IN is high, COM connects to NO; when IN is low, COM connects to NC
- The break-before-make timing prevents momentary short circuits during switching.
Why low RON matters in precision analog circuits:
- 3.5Ω ON-resistance causes a voltage divider effect in the signal path, reducing signal amplitude at high load impedance
- For audio signals (typical 10kΩ input impedance), the 3.5Ω loss is negligible (~0.035%)
- For high-impedance sensor inputs (>1MΩ), the impact is even smaller
- The 5pF ON-capacitance limits bandwidth to 300MHz but is low enough for USB 2.0 (480Mbps) and audio applications.
Key Benefits
Two independent switches in a tiny 2.9x1.6mm package, ideal for space-constrained designs.
Compatible with 1.8V, 2.5V, 3.3V, and 5V systems without level shifting.
Suitable for USB 2.0, audio, and general-purpose analog signal switching.
Automotive-qualified with -40°C to +125°C junction temperature range.
Detailed Specifications
| Parameter | Value | Conditions / Notes |
|---|---|---|
| Device Type | Dual-Channel SPDT Analog Switch | - |
| Manufacturer | Texas Instruments | USA |
| Configuration | 2x SPDT (Dual SPDT) | Independent control |
| Supply Voltage (VCC) | 1.65V to 5.5V | Wide voltage range |
| ON-Resistance (RON) | 3.5Ω (typical) | 25°C |
| ON-Capacitance (CON) | 5pF (typical) | At 1MHz |
| Bandwidth | 300MHz (-3dB) | - |
| Control Interface | Dual IN pins | Independent on/off per switch |
| Break-Before-Make | Yes | Guaranteed |
| ESD Protection | 2kV HBM | - |
| Package | SOT-23-6 (DYY) | 2.9x1.6mm |
| Operating Temperature | -40°C to +125°C | Junction temp |
Note: For detailed electrical parameters, thermal management design, and EMI optimization guidelines, refer to the official TI datasheet. Specifications are subject to change without notice. Engineers should verify all parameters before final design.
Package Information
TMUX1309QDYYRQ1 uses a 6-pin SOT-23 (DYY suffix) package with a compact 2.9x1.6mm body and 0.95mm pitch. This tiny package makes the TMUX1309 ideal for space-constrained applications. The device features dual SPDT (Single-Pole-Double-Throw) switches for signal routing in automotive and portable electronics. AEC-Q100 Grade 1 qualified.
Pin Definition (SOT-23-6)
- NO_1, COM_1, NC_1: Channel 1: Normally Open, Common, Normally Closed
- NO_2, COM_2, NC_2: Channel 2: Normally Open, Common, Normally Closed
- IN_1, IN_2: Control input pins (logic level gates each SPDT)
- VCC / GND: Power supply and ground
Alternative Parts
The following alternative parts are listed for reference. Before selecting an alternative, verify communication interface, supply voltage, security algorithm compatibility, and software API differences.
| Part Number | Brand | Type | Package | Key Feature |
|---|---|---|---|---|
| TMUX1308QBQBRQ1 | TI | 8-Ch 1:8 Mux / SPI / 1.65V-5.5V | QFN-20 | 8-channel version for multi-channel switching needs |
| TS3A27518ERTER | TI | Dual SPDT / 1.65V-3.6V / 3.5Ω | QFN-16 | Higher channel count, wider supply range |
| TMUX1309QDYYRQ1 | Verify datasheet before selection | Verify datasheet before selection | Verify datasheet before selection | Verify datasheet before selection |
Manufacturer Information
Texas Instruments (NASDAQ: TXN), headquartered in Dallas, Texas, is a global leader in analog and embedded semiconductors. TI's TMUX and TS3A switch families cover everything from single SPDT to high-channel-count analog mux devices. The TMUX1309 follows TI's automotive-quality flow with AEC-Q100 Grade 1 qualification and PPAP support.
Applications
Frequently Asked Questions
What is TMUX1309QDYYRQ1 used for?
TMUX1309QDYYRQ1 is used in electronic designs according to the function and limits described in the manufacturer datasheet.
Can TMUX1309QDYYRQ1 be replaced by another part?
Only after verifying package, pinout, electrical limits and software or circuit compatibility.
Where should the final parameters be checked?
Use the official manufacturer datasheet and latest ordering documentation before final design release.
Disclaimer
The technical specifications listed on this page are based on the official TI datasheet. We strive to ensure accuracy and completeness, but specifications are subject to change without notice. Engineers should verify all parameters before final design.
We guarantee all products are genuine factory originals with complete traceability.
Free technical consultation available before and after purchase.
This product page is for reference only.
TMUX1309QDYYRQ1 Specifications
- Specifications
- Attributes
- Property Value
- Manufacturer
- Texas Instruments
- Series:
- -
- Packaging:
- Tape & Reel (TR)
- Part Status:
- Active
- Switch Circuit:
- SP4T
- Multiplexer/Demultiplexer Circuit:
- 4:1
- On-State Resistance (Max):
- 195Ohm
- Channel-to-Channel Matching (ΔRon):
- 7Ohm
- Voltage - Supply, Single (V+):
- 1.62V ~ 5.5V
- Qualification:
- AEC-Q100
- Voltage - Supply, Dual (V±):
- -
- Switch Time (Ton, Toff) (Max):
- 32ns, 40ns
- Number of Circuits:
- 2
- 3 dB Bandwidth:
- 500MHz
- Charge Injection:
- -6.5pC
- Grade:
- Automotive
- Channel Capacitance (CS(off), CD(off)):
- 14pF, 7pF
- Mounting Style:
- Surface Mount
- Operating Temperature:
- -40°C ~ 125°C (TA)
- Current - Leakage (IS(off)) (Max):
- 1nA (Typ)
- Crosstalk:
- -90dB @ 1MHz
- Supplier Device Package:
- 16-SOT-23-THIN
